model |
Number of slots |
Shaft hole |
Inner hole |
60×1B level |
1 |
10-24mm |
24mm |
70×1B level |
1 |
10-24mm |
25mm |
80×1B level |
1 |
10-24mm |
25mm |
90×1B level |
1 |
10-24mm |
25mm |
100×1B level |
1 |
10-24mm |
25mm |
110×1B level |
1 |
10-24mm |
customizable |
120×1B level |
1 |
10-24mm |
customizable |
130×1B level |
1 |
15-24mm |
customizable |
140×1B level |
1 |
15-24mm |
customizable |
150×1B level |
1 |
18-24mm |
customizable |
160×1B level |
1 |
18-24mm |
customizable |
180×1B level |
1 |
18-24mm |
customizable |
200×1B level |
1 |
18-24mm |
customizable |
Note: Tolerance of outer diameter: 2-3mm, support non-calibration.
